SRT's Min6 is the perfect companion to your CRC MetriCKs as well as most other 1/12th scale chassis!

KEY FEATURES

• Special 1/12 pan-car servo
• Supports SXR, SFR, SR, SSR multiple ultra high speed modes
• Incredible efficiency and low power consumption
• 2 µsec Dead Band
• 1-Year Limited Warranty

PRODUCT SPECIFICATIONS

• Type: Digital
• Bearing: Dual
• Motor Type: Coreless
• Gear Type: Metal
• Gear Material: 7075 Aluminum
• Control system: pulse width control
• Working frequence: 1520µs / 333hz
• Operating voltage: dc4.8-8.4v
• Operating temperature range: -10 to + 60 degree
• Operating speed (4.8v): 0.10 sec/60 degrees at no load
• Operating speed (6.0v): 0.08 sec/60 degrees at no load
• Operating speed (7.4v): 0.07 sec/60 degrees at no load
• Operating speed (8.4v): 0.06 sec/60 degrees at no load
• Stall torque (4.8v): 5.0kg.cm (69.4 oz/in)
• Stall torque (6.0v): 6.8kg.cm (94.4 oz/in)
• Stall torque (7.4v): 8.0kg.cm (111.1 oz/in)
• Stall torque (8.4v): 9.0kg.cm (125.0 oz/in)
• Potentiometer drive: direct drive
• Dimensions: 27.2 x 12.1 x 28.2 mm
• Weight: 18.0g

• Connector wire length: jr 170 mm
